Analyse de spectre multivoie

Being able to see the frequency content of a signal is extremely useful for troubleshooting.  Being able to see multiple channels of spectrum analysis, synchronized with signals in the time domain is even more useful. This short video demonstrates the capability of the 5 Series B MSO to display a multi-channel spectrum view along with voltage-vs-time waveforms.

Note: A 5 Series MSO is used in this video, but the same capabilities are available in 4 Series B and 6 Series B MSOs and the operation is identical.
