You're Invited! Booth #1507

Join us at IEEE Applied Power Electronics Conference, March 16-20, at the Georgia World Congress Center. Visit our booth #1507 to experience the latest power testing solutions, as you connect with our experts.

Schedule a personal meeting to discuss your specific application. We look forward to seeing you there.

SCHEDULE A MEETING



Explore Our Showcased Solutions

You’ll find three Tektronix powered double pulse testing solutions at APEC this year, including oscilloscope double pulse testing analysis software and a turnkey double pulse test system offered by our partners, PE Systems at Booth #1507. In addition, our valued customer, Wolfspeed, will be demonstrating how to optimize SiC designs with side-by-side benchmarking at their Booth #1811.


Ensure Accurate, Repeatable Double Pulse Testing for SiC and GaN Designs

  • Meet JEDEC and IEC standards with integrated oscilloscope software
  • Make high-bandwidth gate and drain current measurements with our new isolated shunt probe
  • Make isolated high-side gate voltage measurements
  • Measure switching losses accurately with our patented deskew algorithm
  • Measure Dynamic RDS(on) without external clamping
  • Automatically generate gate driver double pulse signal

LEARN MORE

Flexible Turnkey Double Pulse Testing Systems

  • Modules, discrete silicon, SiC and GaN – one tester for all devices
  • Fast setup times via test code
  • Test voltage up to 2 kV and current up to 3.6 kA
  • Compatible with existing infrastructure

LEARN MORE

Optimize SiC Device and Gate Drive with Side-by-Side Benchmarking

  • Identify gate drive levels to remain in device safe operating area
  • See how Wolfspeed’s Gen 4 technology minimizes switching loss
  • Quantify switching losses with integrated JEDEC compliant analysis
  • Make high-bandwidth Vds, Vgs, and Ids measurements

Simplify Battery Testing with a Turnkey Solution

  • Simplify battery testing with a turnkey solution, featuring integrated software and an intuitive touchscreen
  • Achieve unmatched power density with up to 300 kW in a 42U rack, 2,400 A per rack, all in just 6.5 sq ft of space.
  • Minimize down-time with a modular design and easily swappable units
  • Easily reconfigure or scale testing, ensuring flexibility to meet evolving battery technology needs

LEARN MORE

Versatile High-power Bidirectional Triples

  • Maximize performance with three isolated DC channels, each up to 10 kW, supporting up to 920 V or up to 340 A
  • Consolidate multiple testing setups into one, reducing cost, equipment needs and test time
  • Program and get your data faster with greater than 1 ms response time
  • Deliver full power across a wide operating range with autoranging, which automatically adjusts voltage or current to handle diverse combinations with a single unit
  • Boost efficiency with 96% energy recovery through DC load functionality

LEARN MORE

Space-saving Scalable High-Power Testing

  • Get the highest bidirectional power density on the market – 60 kW in 6U
  • Save space with 360 kW of power from only 6.5 sq ft of floor space
  • Scale up to 3.84 MW of bidirectional power with 11 combined racks
  • Deliver maximum power across wider voltage and current ranges with autoranging
  • Cut costs with >96% energy recovery efficiency
  • Configure high-performance systems with fewer devices

LEARN MORE

Expand 3-Phase Analysis with Automated Inverter and Drive Measurements

  • Perform detailed electrical and mechanical measurements for analysis of 3-phase inverters and motor drives
  • Get quick reliable test setups with stable triggering and phasor diagrams
  • Go beyond volts and amps with efficiency, harmonics, DQ0, torque and speed measurements
  • Document dynamic behavior with measurement trend plots
  • Stream waveform data simultaneously from multiple instruments and analyze together with multi-scope support in TekScope PC

LEARN MORE

Come Hear Tek Experts

Date Presentation Time Location
March 18, 2025 Improving Power System Performance and Power Integrity using Time Domain Reflectometry (TDR) 8:30 – 8:55 AM ET Level Four, A404/A405
March 18, 2025 Smart Motors: Harnessing Sensor Data and AI for Predictive Maintenance 8:55 AM – 9.20 AM ET Level Four, A404/A405

Don’t forget to schedule a personal meeting to discuss your specific application. We look forward to seeing you there.

SCHEDULE A MEETING
