TBS2000B Digital Storage Oscilloscope

The new TBS2000B Digital Storage Oscilloscope is great at performing an oscilloscope's most important jobs - looking at and measuring signals. See more with its bigger 9-inch display with 15 horizontal divisions for more time per screen and 5M record length to capture long time windows. Measure more with handy cursors and powerful 32 automatic measurements. Share more with Wi-fi connectivity and 100-BaseT Ethernet port. This affordable scope delivers the performance you need.

If you're looking for an oscilloscope with serial decode or function generator, learn about the 2 Series MSO touchscreen mixed signal oscilloscope.

Base Price
US $1,640 +
Bandwidth

Up to 200 MHz

Analog channels

2 or 4

Record Length

5M points

Warranty

5 years



See more signals with the large display on the TBS2000B oscilloscope


50% more signal.

When you see more signal, you find anomalies faster. With an impressive 9-inch WVGA display and 15 horizontal divisions —allowing you to see 50% more signal—the TBS2000B digital storage oscilloscope not only helps you see the big picture, it gives you a clearer picture. A 5-million point record length lets you capture long time windows with higher timing resolution. Plus, the updated front-panel waveform navigation controls let you can easily pan and zoom through long records.

Measure signal parameters with confidence

The TBS2000B digital storage oscilloscope is loaded with easy-to-use features. The new front end design with higher 2GS/s sample rate offers lower noise and higher effective bits for more accurate measurements. With 32 automated measurements, you can measure the most commonly-needed parameters easily and more accurately. Analyze your signals with new on-waveform cursor readouts - just like a textbook.

Measure common parameters with 32 automated measures on the TBS2000B oscilloscope
Oscilloscope software solutions for remote teaching and remote learning

Software Solutions

Driven by the rapid transition to remote-hybrid learning, there are a number of new Tektronix software solutions which help remote access, data analysis, as well as remote data sharing and collaboration.

Learn more about each software offering, and how it can enhance the remote reaching lab Learning experience.

New features and options make the best scopes better

NEW Features

  • 5M point record length, 200 MHz bandwidth, and 2GS/s sample rate capture and display significantly more signal to debug and validate designs faster.
  • New lower noise front end design offers lower random noise, better signal integrity and more accurate measurements.
  • TekVPI™ probe interface supports wide range of active, differential, and current probes with automatic scaling and units.
  • On-waveform cursor readouts with search and mark features enable easy identification of events that occur in the acquired waveform.
  • Educators can disable the autoset, cursors, and automated measurements to facilitate teaching basic concepts.
  • Bandwidth is field-upgradeable.
Search and mark parameters easily with the TBS2000B oscilloscope
USB Wi-FI support on the TBS2000B oscilloscope

Control and Share Remotely

The TBS2000B supports remote communication / control via USB or Ethernet. With two USB host ports and a 100BaseT Ethernet port, it is easy to share measurements and collaborate - with your lab partner or across the globe. Plus, the included software lets you easily connect to your PC to grab screen images and analyze data.

Power measurements made easy

The TekVPI™ probe interface sets the standard for ease of use in probing. In addition to supporting standard BNC probes, it also allows you to use the latest-generation active voltage and current probes. TekVPI enables communication between the TBS2000B and the latest current and differential voltage probes, simplifying measurement setups and extending your range of applications.

Highlights

  • Automatically communicate scale factors to the oscillscope.
  • Probe guidance such as open-jaw errors, offset settings and degauss requirements are presented on oscilloscope display.
  • No external power supply is required to power the probe.
The TekVPI probe interface enables communication between the TBS2000B oscilloscope and the latest current and differential probes
The TBS2000B oscilloscope is an affordable and powerful education oscilloscope for university labs

Learn now, use forever.

With the TBS2000B students can take a hands-on approach, thanks to features that make learning engineering fundamentals easier.

Highlights

  • HelpEverywhere offers instant tips - including measurement information, application tips, and general guidance in the form of text and graphics - as you navigate through key menus.
  • TekSmart Lab™ network software helps instructors set up and monitor many instruments from one PC.
  • Courseware ecosystem lets instructors load information into the TBS2000B, to help students during labs.
  • Autoset, cursors, and automated measurements can be disabled to facilitate teaching basic concepts

Accidents happen. Make sure you're protected.

We have the only plan in the industry to offer coverage for accidental damage. Yes, this includes screen damage, spills, broken mounts, and electrostatic discharge or electronic overstress events. Reduce unplanned repair or replacement costs with our Total Protection Plan. Watch the video or click below to learn more.

Learn More

Model Analog Bandwidth Sample Rate Record Length Analog Channels List Price Configure And Quote
TBS2072B 70 MHz up to 2 GS/s 5 Mpoints 2 US $1,640 Configure & Quote
TBS2102B 100 MHz up to 2 GS/s 5 Mpoints 2 US $2,080 Configure & Quote
TBS2074B 70 MHz up to 2 GS/s 5 Mpoints 4 US $2,550 Configure & Quote
TBS2202B 200 MHz up to 2 GS/s 5 Mpoints 2 US $2,940 Configure & Quote
TBS2104B 100 MHz up to 2 GS/s 5 Mpoints 4 US $3,030 Configure & Quote
TBS2204B 200 MHz up to 2 GS/s 5 Mpoints 4 US $3,640 Configure & Quote
Model Analog Bandwidth Sample Rate Record Length Analog Channels List Price Configure And Quote
TBS2072B 70 MHz up to 2 GS/s 5 Mpoints 2 US $1,640 Configure & Quote
TBS2102B 100 MHz up to 2 GS/s 5 Mpoints 2 US $2,080 Configure & Quote
TBS2074B 70 MHz up to 2 GS/s 5 Mpoints 4 US $2,550 Configure & Quote
TBS2202B 200 MHz up to 2 GS/s 5 Mpoints 2 US $2,940 Configure & Quote
TBS2104B 100 MHz up to 2 GS/s 5 Mpoints 4 US $3,030 Configure & Quote
TBS2204B 200 MHz up to 2 GS/s 5 Mpoints 4 US $3,640 Configure & Quote
  Tektronix
TBS2000B
Keysight
X2000
Display 9 inch (800x480) 8.5 inch
Horizontal Grids 15 10
Waveform Display with Menu Off 100% Waveform display with menu-off 80% waveform display, no menu off
Record Length 5M Points 100K Points Standard
1M Points Standard
Connectivity Wi-Fi Dongle Support, USB, LAN USB, optional LAN, GPIB, no WiFi support
Channels 2 or 4 2 or 4
Bandwidth Up to 200Mhz Up to 200Mhz
Sample Rate Up to 2 GS/s Up to 2 GS/s
Automatic Measurements 32 24
Flexible Probes Support TekVPI interface for active, differential and current probe support with probe communication, no external power needed Standard BNC interface, no probe power and communication
Measurements Cursor measurements with on-waveform readouts Cursor measurement readouts are off to the side of the screen
Education Solution TekSmartLab, Courseware, HelpEverywhere, ScopeIntro BenchVue
Frequency Counter 1CH frequency counter 1CH frequency counter
Warranty 5 years 5 years



Embedded Design

The TBS2000B oscilloscope provides the embedded design engineer with a large 9-inch screen that shows 50% more horizontal signal with 15 divisions.

  • Easily pan and zoom through long records with front-panel waveform navigation controls
  • 32 automatic measurements enable you to measure the most commonly needed parameters
  • Built in FFT for quick frequency domain analysis

Power Measurements

The TBS2000B offers flexible probing solutions, so you can measure a wider range of signals without the need for a separate power supply.

  • Supports a wide variety of voltage and current probes with the easy-to-use TekVPI® probe interface
    • Passive Probes
    • Current Probes
    • Differential Probes
    • High Voltage Probes
  • Probes automatically communicate scale factors to the oscilloscope
  • Active probes are powered by the oscilloscope. No external power needed
Oscilloscope probes compatible with the TBS2000B oscilloscope with TekVPI protocol
Students learning engineering concepts with the TBS2000B education oscilloscope

Education

The TBS2000B Oscilloscope offers new features that enable educators to devote more time to teaching engineering concepts and less time on lab setup and management.

  • Built-in Courseware Lab Viewer
  • TekSmartLab Teaching Assistant Applications Software
  • Ability to independently disable AutoSet, Cursors and Measurements
  • Five-year warranty as standard
  • Kensington lock
Accessory ACD4000B
Datasheet Description
View Datasheet Soft Carrying Case
Accessory TEK-DPG
Datasheet Description
Accessory, Deskew Pulse Generator Signal Source with TekVPI Scope Interface
Accessory TEK-USB-488
Datasheet Description
USB TO IEEE488 (GPIB) COMMUNICATIONS ADAPTOR FOR USBTMC-USB488 COMPLIANT TEKTRONIX INSTRUMENTS
Accessory TPA-BNC
Datasheet Description
Probe adapter from TekProbe-BNC to TekVPI
Datasheet Accessory Description
ACD4000B Soft Carrying Case
View Datasheet TEK-DPG Accessory, Deskew Pulse Generator Signal Source with TekVPI Scope Interface
View Datasheet TEK-USB-488 USB TO IEEE488 (GPIB) COMMUNICATIONS ADAPTOR FOR USBTMC-USB488 COMPLIANT TEKTRONIX INSTRUMENTS
View Datasheet TPA-BNC Probe adapter from TekProbe-BNC to TekVPI

Get oscilloscope waveform analysis capabilities right on your PC

Analyze waveforms anywhere, anytime with TekScope PC analysis software. Educators and engineers alike will appreciate the ability to measure and control waveform data from any location and share with remote colleagues and classmates.

  • Recall and view waveforms, perform cursor and automated measurements, create time trends, histograms and spectrum views for free in the base package
  • Use as teaching / learning aid to for Oscilloscopes and basic signal analysis
  • Perform basic instrument control, waveform transfer, analysis and protocol decode on a TBS1000C / TBS2000B oscilloscope with TEKSCOPE-ENTRY license
